NX32 Lite
- Description
The NX32 Lite is a small-sized appliance but don’t let its size fool you. It's the most powerful, performant and reliable appliance powered by 3CX and can be used as a SBC as well as a PBX appliance, ideal for teams up to 150 users (48SC licenses). It comes with 3CX pre-installed and making setup and management child’s play.
- Easy installation - minimum down time
- SBC & PBX Appliance in one
- Supports 250+ SIP Trunks from 50 countries
- Easy management from cloud portal
- Built-in secure tunnel & anti-hacking module
- Value for money 3CX appliance
- Clear and high-quality codecs
- Scalable for future expansion
- Powered by 3CX
Technical Specifications
Resources
Downloads
What’s in the box
Exporting Package Details
Technical Specifications
- CPU: Celeron, Dual Core
- RAM: 6GB
- Storage: 32GB EMMC
- WAN: 1*10/100/1000M
- LAN: 1*10/100/1000M
- USB: 2*USB3.0
- Display: HDMI
- Power Consume: 12V/1A – 12 Watt
- Reset: 1
- Dimension: 118*118*28MM
- Color: Blue
- Power LED: 1
Resources
CE EMC Test Report
CE LVD Safety Test Report
Nx32lite DataSheet
Nx32lite Quick Start Guide
CE EMC Attestation of Conformity
CE LVD Attestation of Conformity
Downloads
You can download the Call4tel NX32 Lite detector files from the below link
What’s in the box
- NX32 Lite: 1
- PSU: 1
- Ethernet cable: 1
- Quick Guide: 1
Exporting Package Details
- Unit Dimension: 230*180*50
- Unit Weight: 0.48kg
- Total Units/Carton: 10 Units/CTN
- Carton Box(Size): 320*390*270
- Weight: 5.6kg
